Review of the Sulzer Mixpac DP2X Pneumatic Cartridge Glue Gun

The Sulzer Mixpac DP2X Pneumatic Cartridge Glue Gun delivers the latest innovations with simple, user-friendly operation. The DP2X boasts one of the best user experiences available on the market today and is used in a wide range of applications including electronics, automotive, aerospace and marine. The DP2X comes in a 200ml or 400ml size with an optional conversion kit. The pneumatic (air-dispensed) feature makes it easy for the user to dispense a precise and repeatable amount of adhesive without worrying about user fatigue.

Overall, working with the Mixpac DP2X ensures high-quality, reproducible results through its user-friendly design and top-tier components. So, let’s discuss the details that make this cartridge gun exceptional.



What are its advantages?

The DP2X takes pride in its unparalleled precision, flexibility, and ergonomic features. To help you make an informed decision, here are the advantages of the Sulzer Mixpac DP2X Pneumatic Cartridge Gun:

Precision

Sulzer offers features that promote the precision of the application of adhesive to any surface. The tool has advanced air regulation and exhaust mechanisms, which respond according to the amount that the end-user needs. In other words, users can gain full control with the pressure applied to the tool to dispense the right amount of material. Its highly responsive system directs precision to eliminate instances of material dripping. All you need to do is place two of your fingers on the precision trigger to control its dispensing performance. Thanks to its air exhaust mechanism, stable rods, and rigid tool frame, there is enough support for mixing and controlling the material that comes out of the device.

Flexibility

The DP2X pneumatic cartridge glue gun features exceptional flexibility. It allows users to monitor the dispensing performance of the device. All they need to do is to check the indicator rod on the frame of the glue gun. From there, you can find the volume of material left in the cartridge. The cartridge release button ejects the empty cartridge quickly and cleanly once the material is all used up.

The conversion kit can hold 1:1, 2:1, 4:1, and 10:1 cartridges in the same DP2X dispenser. This feature offers an all-in-one solution for all your industrial needs. Users don’t need to go through the hassle of utilizing four separate dispensers for their project. Another benefit to this is that the trays can also be suited to the manual MIXPAC DM2X tool.

Ergonomics

The Sulzer Mixpac DP2X Pneumatic Cartridge Glue Gun is lightweight, making it easier to carry and bring around. The dispensing performance is streamlined and improved, featuring a balanced distribution of its weight. Although the Sulzer Mixpac DP2X Pneumatic Cartridge Glue Gun is composed of robust aluminum, it is considerably lighter than other market devices. It is 35% lighter than the dispensers used today.

Here are some of the most significant features of the Sulzer Mixpac DP2X Pneumatic Cartridge Glue Gun:

  • Interchangeable cartridge trays and plungers: Cartridge trays and plungers can be exchanged seamlessly for other cartridge ratios.
  • Plunger Retract Button: The plunger retract button’s location makes it easier for users to access it with one hand.
  • Quick Air Exhaust Mechanism: This mechanism prevents material from dripping after dispensing it.
  • Mounting hook: The purpose of the mounting hook is to suspend the dispenser.
  • Indicator rod: This can help the users check the volume of material left in the cartridge.
  • Ergonomic Grip: Promoting easy handling of the glue gun, DP2X features a grip design that enhances dispensing performance and precision.
  • Cast Aluminum Frame: The frame is made of iron to promote the tool’s durability and efficiency.
  • Cartridge Release Button: You can utilize this to eject the cartridge once the material in it has run out.
  • Integrated regulator: This regulator will adjust the output force quickly and safely, allowing you to have full control over the tool.

The Sulzer Mixpac DP2X Pneumatic Cartridge Glue Gun underwent extensive Finite Element Analysis (FEA) to achieve its ergonomic design. Sulzer experts weigh in their knowledge to make sure that every feature offers unparalleled functionality. They also made sure that the components can withstand operational forces and pressures, promoting durability.

Product Specifications

The Sulzer Mixpac DP2X Pneumatic Cartridge Glue Gun is available in two different cartridge volumes:

DP2X 200 ml Specifications


  • Weight: 1.76kg / 3.87lbs
  • Length: 406mm / 15.9in
  • Maximum thrust: 2.5kN
  • Tool material: cast aluminum and reinforced nylon
  • Cartridge capacity: 200mL
  • Cartridge ratio: 1:1/2:1/4:1/10:1
  • Air inlet: 1/4in NPT
  • Maximum operating pressure: 6.8 bar/100 ps

DP2X 400 ml Specifications


  • Weight: 2.66kg / 5.87lbs
  • Length: 486mm / 19.1in
  • Maximum thrust: 5.0kN
  • Tool material: cast aluminum and reinforced nylon
  •  Cartridge capacity: 400mL
  • Cartridge ratio: 1:1/2:1/4:1/10:1
  • Air inlet: 1/4in NPT
  • Maximum operating pressure: 6.8 bar /100 psi

Final Thoughts

A functional cartridge gun is imperative for any adhesive industrial task. The DP2X pneumatic cartridge gun aims to make your job easier while yielding long-lasting results. The device design provides the best user experience. We are a top US distributor for Sulzer Mixpac. If you are interested in this product, place your order today or contact us to speak to a Gluegun.com expert.
