ASI MG Series Medical Grade Cyanoacrylate Super Glue

SKU: ASI MG005-10

Manufacturer Part #: MG005-10


Price:
Sale price$270.00

⚠️ Limited supply.

Product Highlights

  • Type: Cyanoacrylate Super Glue
  • Brand: Adhesive Systems, Inc.
  • Set Speed: Fast
  • Bonds: General, Metal, Plastic
  • Properties: Medical Grade

About the ASI MG Series Cyanoacrylate Super Glue

The Adhesive Systems Inc (ASI) MG Series cyanoacrylate super glue is a medical grade adhesive used to create fast, permanent bonds. The MG Series super glue has a USP Class VI certification and are often used in manufacturing or assembly medical devices.

Benefits of the ASI MG Series Cyanoacrylates

  • USP Class VI Certification
  • Fast, permanent bonds
  • Perfect for medical device assembly
  • Single component (no mixing or nozzles required)
  • Cures at room temperature
  • Good for bonding most substrates
  • Fast cure time
  • Dispensing can be automated
  • Long term bonds
  • Economical
  • Meets most military (MilSpec) standards
  • Can replace heavy mechanical fasteners

ASI MG Series Cyanoacrylate Specifications

ASI MG Series Properties

  • COLOR: Clear
  • VISCOSITY: 5 cps
  • BASE: Ethyl
  • STRENGTH: 2700/4300
  • TEMPERATURE RANGE: - 65 - 200°F
  • CURE SPEED: 15 seconds
  • (FIXTURE)
  • FULL CURE: 8 hours
  • MIL A 46050 Type II
  • Class I
  • SPECIFIC GRAVITY 1.05
  • SOLUBLE IN: Remove Debonder

ASI MG Series Chemical and Solvent Resistance

Percent of Strength Retained After Aging for 500 Hours

  • GASOLINE @ 220C: 100%
  • ISOPROPANOL @ 220C: 100%
  • ETHANOL @ 220C: 1005
  • FREON TA @ 220C% 100%
  • MOTOR OIL @ 400C% 100%
  • POLYCARBONATE 400C @ 95% RH 100>%

ASI MG Series Cure Time and Bond Strength By Substrate

  • Steel < 10 Seconds > 2100 psi
  • Aluminum < 10 Seconds > 1750 psi
  • Neoprene < 5 Seconds > 750 psi
  • ABS < 7 Seconds > 900 psi
  • PVC < 5 Seconds > 900 psi
  • Polycarbonate < 7 Seconds > 900 psi
  • Phenolic < 7 Seconds > 850 psi

ASI MG Series Specifications by Viscosity

PRODUCT GAP FILL VISCOSITY STRENGTH TEMP RANGE CURE SPEED (FIXTURE/FULL) MIL SPEC A 46050C
MG 5 0 5 cps 2700/4300 -65 to +200° F <15 Sec/8 Hours Type II, Class 1
MG 30 0 30 cps 2700/4300 -65 to +200° F <15 Sec/8 Hours Type II, Class 1
MG 100 0.01 100 cps 2700/4300 -65 to +200° F <15 Sec/8 Hours Type II, Class 2
MG 500 0.01 500 cps 2700/4300 -65 to +200° F <15 Sec/8 Hours Type II, Class 2
MG 1000 0.01 1,000 cps 2700/4300 -65 to +200° F <15 Sec/8 Hours Type II, Class 3
MG 1500 0.01 1,500 cps 2700/4300 -65 to +200° F <15 Sec/8 Hours Type II, Class 3
MG 2400 0.01 2,400 cps 2700/4300 -65 to +200° F <15 Sec/8 Hours Type II, Class 3
MG 4000 0.01 4,000 cps 2700/4300 -65 to +200° F <15 Sec/8 Hours Type II, Class 3

ASI MG Series Cyanoacrylate Data Sheets

ASI MG Series Technical Data Sheets

ASI MG Series Safety Data Sheet

Questions about ASI MG Series? Our team of adhesive specialists can help. Submit your questions and we'll get you answers right away.

Guaranteed Safe Checkout

American Express Apple Pay Diners Club Discover Meta Pay Google Pay Mastercard PayPal Shop Pay Venmo Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Compare with Similar Products

ASI MG Series medical grade cyanoacrylate super glue
ASI MG Series Medical Grade Cyanoacrylate Super Glue
Infinity Bond CA MG Medical Grade 1 oz
Infinity Bond Medical Device Super Glue Cyanoacrylate
Best Seller
Price $$$$$ $$$$$
Type Cyanoacrylate Super Glue Cyanoacrylate Super Glue
Brand Adhesive Systems, Inc. Infinity Bond
Viscosity 5 - 4,000 cps5 - 4,000 cps
Temp Resistance -65F to 200F-65F to 180F
Color ClearClear
Size 1 oz bottle
2 oz bottle
1 lb bottle
4.4 lb bottle
1 oz bottle
1 lb bottle

These values are approximate. Manufacturers often use different parameters for determining adhesive properties. Refer to manufacturer data sheets for detailed specifications. If you have questions, don't hesitate to contact us.
